Digifast M.2 NVMe SATA RGB Cloner And Eraser 1-1, Customizable RGB Design, Cross Duplication, Copy up to 24 GB/min
Click to enlarge

Digifast M.2 NVMe SATA RGB Cloner And Eraser 1-1, Customizable RGB Design, Cross Duplication, Copy up to 24 GB/min Digifast M.2 NVMe SATA RGB Cloner And Eraser 1-1, Customizable RGB Design, Cross Duplication, Copy up to 24 GB/min

$1,750.00 USD
SKU: DFMR240

Description

DFMR240 is the first RGB M.2 duplicator in the world. It’s lightweight and portable design allows users to duplicate quickly from anywhere. This copier supports NVMe and SATA protocols enabling cross-signal and cross-interface duplication for maximum versatility. The brilliant RGB LED light display and modular sockets are traits that set it apart from traditional bulky duplicators.

Feature


Speed of Up to 24GB/min
Cross-duplication
M.2 ports automatically detect NVMe and SATA protocols producing rapid cross-signal and cross-interface duplication.
Unique RGB LED Design
The first duplicator of its kind, featuring five customizable RGB lighting effects.
Globally the first design for 5 RGB lighting effects and easily switch.
Erasing Functions
Erase functionality compliant with NIST 800-88 and DoD 5220 standards.
Secure and enhance secure erase functions wipe drive contents within seconds.
Modular socket design allows easy replacement of overused ports.



LCD Display2 x 20 OLED Display
LEDs3 LED indicators per port: Yellow (Power), Green (Pass), and Red (Fail)
Control Panel4 Push Buttons (▲, ▼, OK, ESC)
Power RequirementsPower Input: Universal Power 115VAC or 230VAC, 50/60Hz Power Output: 12VDC 5A
Operational Temperature0°C ~ 60°C (32°F ~ 140°F)
Non-operational Temperature-20°C ~85°C (-4°F ~ 185°F)
HumidityOperating: 20% ~ 95%, non-condensing | Non-operating: 5% to 95%, non-condensing
CertificationFCC, CE, RoHS, and REACH
Compatible DevicesAll NVMe and SATA devices with the M.2, 2.5”, and 3.5” form factors.
Supported InterfacesM.2 B+M Key, M Key, SATA
Supported FormatsQuick Copy Function: FAT16/32/64, Windows (NTFS), Linux (Ext2/Ext3/Ext4), and Mac (HFS, HFS+, HFSX). Whole Device Copy Function: All Formats, including proprietary formats. GPT, MBR, and Advanced Formats.
Supported OSAll (Windows, Mac, Linux, and other proprietary systems).
OriginTaiwan

**For more detail on the specs sheet please contact info@digifast-usa.com

Q1. What is a modular socket?

When connecting devices to a socket thousands of times, the connection will begin to wear out. For other duplicators, this would require purchasing a new duplicator. With the Digifast modular socket, the user need only replace the socket saving time and money.

Q2. Can I use both source ports or both target ports at the same time?

Only one port (M.2 or SATA) can be active on each side of the machine at a given time. This device will only copy from one of the source ports to one of the targets ports. For erasing, there is a setting to allow erasing for both source and target ports. This feature will only work for one M.2 or SATA on a side at a given time. In other words, for copy it will always be one to one. For erase, you can do a maximum of two.

Q3. Do the erase functions comply with NIST or DoD standards?

Yes, the full and secure erase options are compliant with NIST 800-88. DoD erase functions are compliant with DoD 5220.22M standards.

Q4. What is the feature of the M.2 duplicator?

Stand-alone design FPGA operation. (Non-PC based design)
Dedicated bandwidth enables high volume duplication without speed compromise.
Light-weight form factor that packs a powerful punch, which provide peak transfer speed of up to 10 or 24 GB/min.
